Product description




| 1. Ambient temperature: 10~30℃; |
| 2. Relative humidity: ≤75%; |
| 3. Atmospheric pressure: 860~1060hpa; |
| 4. Power supply: AC220V±10%, 50Hz±2%; |
| 5. Cooling water: use deionized water or pure distilled water, the lowest standard pure water. |
| (2) Basic parameters: 1. Geometric size (without articulated arm, length×width×height, mm): 90×44×96cm; |
| 2. Net weight of machine: 68kg; light guide wall 4kg; gross weight 117kg |
| 3. Power: 2000W; |
| 4. Model of overcurrent protector: 220V, 10A |
| 5. Working laser wavelength: 1064nm; 755mm; 532nm |
| 6. Laser output frequency: 1-10hz; |
| 7. Spot diameter: 2-10mm adjustable; |
| 8. The maximum output energy of a single pulse: 1064nm (1064: 0.1~2.0j); 755mm (0.05~1.0j); 532nm (0.05~1.0j); |
| 9. Eye hazard distance: NOHD is 100m. It is harmful to the eyes in a sealed operating room, so you must wear protective goggles |
| 10. Cooling method: built-in closed circulation water cooling type; |
